Description

Bauer MARINER 200 – E
High pressure compressor, 200 l/min, 4,0 kW, three-phase motor 400 V, 50 Hz, P21 filter system

Scope of delivery Basic version:
Fully operational compressor system, consisting of:

Compressor block 3 cylinders, 3-stage
Micronic intake
Intercooler / aftercooler
Intermediate / final separator for oil / water condensate
Intermediate pressure safety valves after each compressor stage
End pressure safety valve type tested according to T?V
oil lubrication
Pressure holding / check valve after the last compressor stage
Three-phase motor
Motor protection switch and connecting cable including plug

Support frame in vibration-optimized construction
Lightweight construction through the use of aluminum alloys
Filter system P 21 with long-term filter cartridge TRIPLEX
Filling device PN 200 or PN 300 bar, 2 filling connections each consisting of:
1 filling hose, 1 m long
1 filling valve PN 200 or 300 bar, with automatic ventilation and manometer;
Threaded connection R 5/8 “, according to DIN EN 144-2
For 200-bar systems: 1 international filling connection (not approved in Germany)
Operating instructions with spare parts list, CE conformity declaration, pressure vessel certificates
Capacity: 200 ltr/min
Pressure: 225 Bar
E-Motor: 400 Volt – 50 Hz – 3 Kw
Dimensions: ca. 1300 x 600 x 630 mm (L x B x H)
Weight: ca. 115 kg
Filter: P-21
