GRID™ 20
AED 1,209.00 Original price was: AED 1,209.00.AED 1,088.00Current price is: AED 1,088.00.
Get instant Cash | Home pickup or Store drop-off More details >
- Description
- Additional information
- SPECS
- IN THE BOX
Description
Description
Sit back and take control
Provides intuitive, easy-to-use remote access and control of your entire Garmin marine system
360-degree, all-in-one joystick with a rotary knob and push-to-select button
Enables easy chartplotter menu/setting navigation and fine control, even in the worst conditions
Four favourite keys can be designated to restore your system to a previously saved configuration
Allows wired or wireless installation options
The easy-to-use GRID 20 remote input device provides intuitive remote access and control of your entire Garmin marine system. It features a 360-degree joystick with a rotary knob and push-to-select button for easy chartplotter menu/setting navigation and fine control, even in the worst conditions. You can designate four favourite keys to restore your system to a previously saved configuration. There are also a variety of hard keys for quick access to important functions, including left and right screen switches, autopilot standby/engage and more. For peace of mind, there’s also a dedicated SOS key. Wired or wireless installation and vertical or horizontal options allow for a plug-and-play solution that is tailored to your marine system. Its small footprint makes it convenient to integrate into a busy helm between displays — or even into the arm of the captain’s chair.
Additional information
Additional information
Series | |
---|---|
Version | VERTICAL |
SPECS
Dimensions (W x H x D): 14.1 x 5.6 x 6.8 cm
Weight: 179 g
Temperature range: From -15° to 70°C
Material: Fully gasketed, high-impact plastic
Water rating: IPX7
Compass-safe distance: 114 mm
Power input:
NMEA 2000
-or-
Wired power (with included power cable):
Input power: 9-32 V DC
Fuse: 1.0 Amp, Fast Blow
Maximum power usage at 9 V DC: 1.5 W
Typical current draw at 12 V DC: 40 mA
Maximum current draw at 12 V DC: 120 mA
-or-
2 x AA battery powered (not included)
IN THE BOX
GRID 20
Mounting hardware
Power cable
Documentation
