-10%
GPSMAP® 922 Plus
Non-sonar with Worldwide Basemap
Original price was: AED 5,239.00.AED 4,716.00Current price is: AED 4,716.00.
- Description
- Additional information
- SPECS
- IN THE BOX
Description
Description
ADVANCED NAVIGATION. ULTIMATE INTEGRATION.
The bright, sunlight-readable 9” intuitive touchscreen chartplotter with enhanced map drawing is easy to use in any environment and seamlessly integrates into your Garmin marine system.
Easily integrate with more engines
Connect to your favourite third-party devices
Easily build your marine system using the best of network connectivity
Compatible with premium maps and charts for the best in Garmin navigation
Take the guesswork out of sailing with clear laylines and more, right on the screen
Manage your marine experience from nearly anywhere
GARMIN SAILASSIST™ SAILING FEATURES
View laylines, race start line guidance, enhanced wind rose, heading and course-over-ground lines, true wind data fields and tide/current/time slider, wind angle, set and drift, wind speed and more.
OPTIONAL BLUECHART® G3 VISION® CHARTS
These optional charts offer the best of Garmin and Navionics ® data, Auto Guidance technology and other premium navigation features 1 .
GARMIN MARINE NETWORK
If you have multiple Garmin devices on your boat, you can share information – such as charts, user data, radar and IP cameras – among them.
NMEA 2000® AND NMEA 0183 NETWORKS
Connect to autopilots, digital switching, weather, FUSION-Link™ audio system, media, VHF, AIS and more from one screen.
ACTIVECAPTAIN® APP
Built-in Wi-Fi ® connectivity pairs with the free all-in-one mobile app for access to the OneChart™ feature, smart notifications 2 , software updates, Garmin Helm, Garmin Quickdraw™ Community data and more.
INTEGRATED ANT® TECHNOLOGY
Connect with some of your favourite devices, such as quatix® marine watches, gWind™ Wireless 2 transducers , GNX™ Wind marine instruments and wireless remote controls.
J1939 CONNECTIVITY
Now you can connect your chartplotter to different kinds of engines, including Yamaha engines.
ONEHELM™ FEATURE
This exclusive feature brings together all the operations and capabilities of third-party devices, such as EmpirBus ™ digital switching, on one screen.
PANOPTIX™ SONAR SUPPORT
Pair with Panoptix or Panoptix LiveScope™ easy-to-interpret live sonar (transducer sold separately) to see all around your boat in real time.
Additional information
Additional information
| Series | |
|---|---|
| Display Size | 9" |
| Sonar Type | None |
| Bundle | No |
SPECS
General |
|
| Dimension | 25.6 x 16.2 x 5.2 cm |
|---|---|
| Touchscreen | |
| Input | Touchscreen |
| Display Size | 7.7″ x 4.5″; 9.0″ diagonal(19.6 cm x 11.4 cm; 22.9 cm diagonal) |
| Display Resolution | 1024 x 600 pixels |
| Display Type | WSVGA display |
| Weight | 1.2 kg |
| Water rating | IPX7 |
| Mounting Options | Bail or flush |
Maps & memory |
|
| Accepts data cards | 2 microSD™ cards; 32 GB max |
|---|---|
| Waypoints | 5,000 |
| Track points | 50,000 |
| Tracks | 50 saved tracks |
| Navigation Routes | 100 |
Sensors |
|
| Has built-in receiver | |
|---|---|
| Receiver | 10 Hz high-sensitivity |
| NMEA 2000® compatible | |
| NMEA 0183 Compatible | |
| GPS | |
| GLONASS | |
| Supports WAAS | |
Built-in Maps |
|
| (Sounder) Tide tables | |
|---|---|
Optional Map Support |
|
| BlueChart g3 | |
|---|---|
| BlueChart g3 Vision | |
| LakeVü g3 | |
| LakeVü g3 Ultra | |
| Garmin Navionics+™ | |
| Garmin Navionics Vision+™ | |
| (Sounder) TOPO | |
| Standard Mapping | |
| Garmin Quickdraw Contours | |
| Raster chart support | |
Chartplotter Features |
|
| Garmin SmartMode compatible (customisable monitor presets) | |
|---|---|
| AIS | |
| DSC | |
| Supports Fusion-Link™ compatible radios | |
| GSD Black Box Sonar Support | |
| GCV™ Black Box sonar support | |
| ActiveCaptain Mobile Planning Compatible | yes |
| GRID™ (Garmin Remote Input Device) compatible | |
| Wireless remote compatible | |
| sailing-features | |
| OneHelm support | |
Sonar Features & Specifications |
|
| Displays sonar | |
|---|---|
| Traditional sonar (dual frequency/beam) | Yes (with external black box, sold separately) |
| ClearVü | Yes (with external black box, sold separately) |
| (Sounder) SideVü | Yes (with external black box, sold separately) |
| Panoptix™ sonar | |
| LiveScope | |
Connections |
|
| NMEA 2000 ports | 1 |
|---|---|
| Connections NMEA0183 Input Ports | 1 (Differential) |
| NMEA 0183 input (Tx) ports | 1 |
| Video input ports | 1 BNC |
| Video output ports | None |
| J1939 ports | 1 |
| Connections Garmin Marine Network Ports | 1 |
| Bluetooth® calling | |
| ANT+ (Connectivity) | |
| Garmin Wi-Fi network (local connection) | |
Electrical Features |
|
| Power Input | 10 to 32 Vdc |
|---|---|
| Typical current draw at 12 Vdc | 1.2 A |
| Maximum current draw at 12 Vdc | 2.3 A |
| Maximum power usage at 10 Vdc | 27W |
IN THE BOX
GPSMAP 922 Plus Chartplotter
Power cable
Bail mount with knobs
Flush mount kit with gasket
Protective cover
Trim piece snap covers
Documentation
