HIGH-DEFINITION MAGNETRON RADAR AT A VALUE PRICE

Name: GMR™ 18 HD3
SKU: 010-02843-00
Availability: OutOfStock

This compact 18″ dome radar combines ease of use with powerful scanning features that work to maximise your confidence and situational awareness on the water.

4kW POWER OUTPUT, 36-NAUTICAL MILE MAX RANGE

SPACE-SAVING 18″ DOME

MARPA TARGET TRACKING

DYNAMIC AUTO GAIN AND SEA FILTER

DUAL-RADAR SUPPORT

QUIET DOME DRIVE MOTOR

DUAL-RADAR SUPPORT

Using dual radar provides redundancy and allows each display unit on the boat to pull data from one of two different radar sources.

DYNAMIC AUTO GAIN

Gain automatically adjusts levels to optimum settings.

DYNAMIC SEA FILTER

Radar gain automatically adjusts sea clutter for calm, medium and rough sea conditions.

RADAR OVERLAY

Overlay radar images onto your chartplotter’s map page. You can add an optional autopilot or heading sensor (sold separately) for best results.

MARPA TARGET TRACKING

MARPA tracks selected targets to help keep track of other vessels and avoid collisions (with appropriate sensors, sold separately).

LOW-NOISE SCANNING

The reliable GMR HD3 dome drive motor spins at a fixed 24 rpm, offering reliable, low-noise operation and minimal power consumption.

COMPACT AND POWERFUL

4kW of transmit power, 36-nautical mile maximum range and clear echo definition at all ranges.

CLOSE-IN TARGET SCANNING

Minimum scanning range of 20 metres for excellent short-range detection and target detail.

HIGH-RESOLUTION RADAR

8-bit true colour for outstanding target separation with less screen clutter.

TIMED TRANSMIT MODE

Specify transmit times down to the seconds to help reduce power consumption.

INTUITIVE OPERATION

No complex user settings, so it’s easy to install and start using.

Engineering enhancements are ongoing and may not be reflected in the pictures, videos and specifications.

In The Box

GMR 18 HD3 dome radar
Power cable (15 m/49.21 ft)
Network cable (15 m/49.21 ft)
Mounting hardware kit and template
Installation instructions

Specs

General
Dimension	20″ diameter, 9.8″ high (508 mm diameter, 248 mm high)
Weight	7.0 kg
Water rating	IPX7
Antenna Length	17″ (43 cm)
Rotation speed (RPM)	24 rpm
Beam width	5.2° horizontal, 25° vertical
Maximum range	36 nm
Minimum range	20 metres
Radar type	Radome

Electrical features
Power Input	11 – 32 V DC
Power Consumption (standby)	15 W
Typical power consumption, transmitting (normal mode)	40 W
Transmit power	4 kW

Radar features
Overlay
Dual radar support
Auto Gain	Dynamic
MARPA target tracking	Yes (requires heading sensor, sold separately)
