Garmin Striker Vivid 4Cv Ww W/Gt20
With GT20-TM Transducer
Original price was: AED 1,019.00.AED 917.00Current price is: AED 917.00.
Series
STRIKER
Display Size
Sonar
Includes Transducer
- Description
- Additional information
- SPECS
- IN THE BOX
Description
Description
THE CHOICE IS YOURS
See fish and structure in maximum detail when you pick your display colour, your location and your sonar for your day on the water with the STRIKER Vivid 4cv fishfinder with transducer.
The sonar colour you pick says a lot about your fishing style. Good thing there are 7 new vivid options.
What a view. Use the included transducer to get CHIRP traditional and ClearVü sonars.
Never lose a hot spot again. Use waypoint marking to find your way back.
What’s under the water’s surface looks pretty good as 1-foot contours, just saying.
CLEAR, COLOURFUL SONAR
Choose from 7 new vivid colour options to see fish and structure in maximum contrast and clarity on your 4-inch fishfinder.
BUILT-IN SONAR
Use the included GT20 transducer to get Garmin CHIRP traditional sonar and CHIRP ClearVü scanning sonar.
WAYPOINT MARKING
To catch more fish, you need to know where the fish are biting. Use waypoint marking for hot spots so you can easily find your way back.
HIGH-SENSITIVITY GPS
Plan and create routes and view your boat’s speed on your fishfinder using high-sensitivity GPS.
QUICKDRAW CONTOURS
Nobody knows the waters you fish better than you. With the STRIKER Vivid 4cv fishfinder, you can store up to 2 million acres of maps with 1-foot contours.
INCLUDED HARDWARE
The STRIKER Vivid 4cv fishfinder includes a tilt/swivel mount plus transom and trolling motor mounting hardware and cable.
Additional information
Additional information
| Series | |
|---|---|
| Display Size | 4" |
| Sonar Type | CLEAVRU AND TRADITIONAL CHIRP |
| Includes Transducer | Yes |
SPECS
General |
|
| Dimension | 3.9” x 6.9” x 1.8” (9.8 x 17.4 x 4.5 cm) |
|---|---|
| Input | Keyed |
| Display Size | 2.1″ x 3.7″ (5.4 x 9.5 cm); 4.3″ diag, (10.9 cm) |
| Display Resolution | 272 X 480 pixels |
| Display Type | QSVGA |
| Weight | 0.7 lbs (0.3 kg) |
| Water rating | IPX7 |
| Mounting Options | flush, tilt/swivel |
Maps & memory |
|
| Waypoints/favourites/locations | 5000 |
|---|---|
| Track points | 50,000 |
| Tracks | 50 |
| Navigation Routes | 100 |
Sensors |
|
| Has built-in receiver | |
|---|---|
| Receiver | Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü 260/455/800 kHz |
| GPS | |
| Supports WAAS | |
Optional Map Support |
|
| Garmin Quickdraw Contours | |
|---|---|
Sonar Features & Specifications |
|
| Displays sonar | |
|---|---|
| Traditional sonar (dual frequency/beam) | Built-in |
| ClearVü | |
| Frequency | Traditional: 50/77/200 kHz CHIRP (mid and high) ClearVü: 260/455/800 kHz |
| Bottom lock (shows return from the bottom up) | |
| Water Temperature Log | |
Connections |
|
| 4-pin transducer ports | 1 |
|---|---|
Electrical Features |
|
| Power Input | 12 to 20 Vdc |
|---|---|
| Typical current draw | 0.40 A |
| Max current draw | 1.5 A |
| Power Consumption | 4.8 |
| Transmit power | 300 W (RMS) |
Fishfinder Features |
|
| Split-screen zoom | |
|---|---|
| Fish Symbol ID (helps identify fish targets) | |
| AutoGain Technology (minimises clutter, maximises targets) | |
| Adjustable depth line (measures depth of underwater objects) | |
| A-scope (real time display of fish passing through transducer beam) | |
| Water temperature sensor included | |
| Depth range shading | |
Additional |
|
| Additional |
One 4-pin transducer port Quickdraw Contours Integrated GPS Mark Waypoints Course over Ground (COG) Current draw @ 12V: 0.40A |
|---|---|
IN THE BOX
STRIKER Vivid 4cv
GT20-TM transducer
Power/data cable
Tilt/swivel mount
Hardware
Documentation
